Fixed Humidity and Temperature Measurement Probe for harsh environment
Features
Designed for accurate measurement in a harsh environment
Can withstand temperatures up to 150°C
Stainless steel housing
Calculated moisture signal output, optional
The DT722 is a rugged industrial relative humidity and temperature transmitter designed for process applications where accurate, stable measurement and control of humidity and temperature is required.
Specifications
| DT722 | |
| Type | Fixed probe |
| Markets | Heavy Industry |
| Operating Range | -30…70 °C / 10…95 %RH |
| Measuring Range | -40…150 °C / 10…95 %RH non condensing |
| Accuracy at 23°C | ±2 %RH / ± 0.2 K |
| Long-term Stability | <1 % rH / year |
| Dimensions | 200mm / 300mm / 500mm/ 900mm |
| Display | With Display |
| Power Supply | 8…32 VDC |
| Output Parameter | Humidity and Temperature |
| Calculated Parameters | Calculated moisture signal output, optional |
| Output | 2 wire: 4…20 mA |
| Output Signals | 4…20 mA |
| Housing Type | Duct mount |
| Housing Material | Stainless steel |
Suitable Applications
